Steel plate welding machine transformer heat sink heating panel production line

Name: Steel plate welding machine transformer heat sink heating panel production line
Brand: Shanghai Trintfar Intelligent Equipment Co., Ltd.
SKU: FVM-170KVA
Price: 30,000.00 USD
Availability: InStock

Tüm ürünler

Punta Kaynak Makinaları
(49)

Enerji depolama kaynak makinesi
(15)

Özel kaynak makinesi
(46)

Transformer Radyatör Fin Üretim hattı
(14)

Dikiş Kaynak Makinesi
(44)

saplama kaynak makinesi
(19)

Çelik Varil Kaynak Üretim Hattı
(34)

Projeksiyon Kaynak Makinası
(18)

Alın Kaynak Makinası
(40)

Fiber Lazer Kaynak Makinesi
(31)

Difüzyon Kaynak Makinesi
(6)

Tel Örgü Kaynak Makinesi
(9)

robot kol
(16)

Diğer Kaynak Makinesi
(44)

En iyi ürünleri

Metal Delikli Paslanmaz Çelik Hasır Silindir Boru Tüp Filtre Kaynak Makinesi

Sertifika

Müşteri yorumları

E-posta adresime veya WhatsApp'a da ulaşabilirsiniz. Cevabını bekliyorum. sales-ftt@trintfar.cn WhatsApp: +86 15216883036 Shanghai Trintfar akıllı ekipman Co. Ltd.

—— Sevgili dostlarım.

Ben sohbet şimdi

Steel plate welding machine transformer heat sink heating panel production line

Büyük resim : Steel plate welding machine transformer heat sink heating panel production line

Ürün ayrıntıları:

Menşe yeri:	Çin
Marka adı:	TRINTFAR
Sertifika:	CE
Model numarası:	FVM-170KVA

Ödeme & teslimat koşulları:

Min sipariş miktarı:	1
Fiyat:	USD 10000-50000 set
Ambalaj bilgileri:	Ahşap Kutu
Teslim süresi:	Son ödemeden sonraki 90 gün içinde
Ödeme koşulları:	L/C, D/A, D/P, T/T
Yetenek temini:	yılda 50

İletişim

Steel plate welding machine transformer heat sink heating panel production line

Açıklama

Makine Kapasitesi::	120m/dakika	Garanti Sonrası Servis:	Videolu teknik destek
Otomatik derecelendirme:	Otomatik	Durum:	YENİ
Gerilim:	220V/380V	Güç(w):	220-450KW
İsim:	Yüksek Verimli Çin Çelik Levha Radyatör Üretim Hattı	Çekirdek bileşenler::	PLC, Motor, Rulman, Şanzıman, Motor, Basınçlı kap, Dişli,

High Efficiency China Steel Plate Radiator Production Line

Feature

Juntengfa has developed an automated production line for plate heat exchangers in the home appliance industry. The production process is mainly spot welding and seam welding edge sealing, so the production is efficient and stable. This production line includes servo motors, electric welding equipment, intermediate frequency seam welding equipment, PLC control and other components. This production line is highly automated, and can automatically load and unload materials and weld plate radiators. Automation can continue to produce 24 hours without any impact. It is an effective solution for mass production of plate devices.

1. High degree of automation, automatic loading and unloading and welding;

2. Faster to reach the set current, fast welding speed;

3. Use intermediate frequency power supply to save energy consumption and reduce production costs;

4. Reduce the parallel connection of secondary circuits without disturbing the power grid;

5. The welding is firm, the weld seam has high air tightness, and the yield rate is high;

6. The production line has strong reliability and can continue to produce 24 hours a day;

7. Customized, plate radiators of various specifications can be produced.

Specification

FVM-170KVA	parameters
Input voltage	380±10% (three-phase) 50HZ
Input power	2x250KVA
Secondary Voltage	11.3V
Maximum short circuit current	50KA
Insulation resistance	Input power to the fuselage insulation resistance ≥ 2.5MΩ
Working environment	temperature≤40℃, humidity≤90%
Cylinder model	Φ160*80
Maximum working pressure	12000N
Air source pressure	0.6MPa
Water source pressure	0.15MPa~0.30MPa
Water flow	30L/min
Welding wheel diameter	280mm
